Tozen Cast Iron Globe Valve Flanged PN16

• Rising stem, Outside Screw and Yoke, Bolted Bonnet.
• End connection: PN16
• Oper.: Handwheel
• Body & Bonnet: Cast iron
• Disc: Stainless steel (DN15-DN50), Cast iron (DN65~200)
• Disc Ring: Stainless steel
• Seat Ring: Stainless steel
• Stem: Stainless steel
• Packing: Graphite
• Handwheel: Cast iron
• Working  Pressure/ Temperature: 16 bar at -10oC~120oC, 10 bar at 200oC
• Testing pressure:  Shell: 1.5 times, Seat: 1.1 times
• Suitable Fluid: Water, Oil & Steam
