JSV-FF200 - Safety Relief Valve Flanged end JOKWANG KOREA

Price: Contact

Model: JSV-FF200

Safety Relief Valve Flanged end

Status: Order
Model: JSV-FF200

Trademark: JOKWANG

Origin: Korea

Order

Project details Download Catalogue Evaluate

JSV-FF200
(Conventional Type)

It is used as a safety relief valve in the piping of gauging devices and various pressurized containers in power boilers and power generators.

It has acquired certification for capacity and quality from the ASME ("UV" stamp). Made of various materials, it can be used in high temperatures, high pressures and for corrosive liquids. It has acquired certification from the Occupational Safety & Health Agency and The Korea Gas Safety Corporation. The standards of API STD 527 for leakage is applied.

Product specification

FORMAT	CERTIFICATION	SIZE	OFRICE AREA	ORIFICE DIAMETER	CORRECT PRESSURE TO BE APPLIED	HOW TO CONNECT THE ITEM	CORRECT TEMPE RATURE TO BE APPLIED	CRITERION FOR LEAKAGE
Conventional Type	V & UV Stemp Occupational Safety & Health Agency, Korea Gas Safety Corporation	1" x 2" ~ 14" x 18"	F(282.58㎡)~Y (49082.48㎡) / F(0.438in²) ~ Y(76.078in²)	F(19.0mm)~Y(250.0mm) / F(0.748n) ~ Y(9.842in)	0.1~34.61MPa (1.05~352.94kgf/cm²)	Flanged,Welded	Max. 604°C	API Standard 527
