NON-Metallic Sheets & Gaskets

Gambit Compressed Non-Asbestos Sheets & Gasket Model: PARO-GAMBIT®

Price: Contact

  • Model: PARO-GAMBIT®

    • Gambit Compressed Non-Asbestos Sheets & Gasket

    Model: PARO-GAMBIT®



  • Trademark: WOOJU GASPACK
  • Origin: Korea
    • Project details Download Catalogue Evaluate

    Material

    • Carbon fibers, mineral fibers, + NBR binder

    Characteristic

    • A high-performance sheet, recommended mostly for installations working with steam.

    Specifications

    Maximum Working Conditions
    Peak Temperature ℃ 450
    Temperature Under Continuous Operation ℃ 350
    Temperature Under Continuous Operation With Steam ℃ 350
    Pressure MPa 10
    Physical and Chemical Properties
    Density (±5%) g/cm3 1.9 DIN 28090 - 2
    Transverse Tensile Strength (min.) MPa 10 DIN 52910
    Compressibility (Typical Value) % 11 ASTM F36
    Elastic Recovery (min.63280) % 55 ASTM F36
    Residual Stress 50MPa/16h/300℃ (min.) MPa 32 DIN 52913
    Residual Stress 50MPa/16h/175℃ (min.) MPa 35 DIN 52913
    Increase In Thickness
    Oil IRM 903 150℃/5h (max.) % 12 ASTM F146
    Color Ginger
