Flexible Sprinkler Drops

HD-FLEX flexible sprinkler drops are stainless steel flexible hoses, which enable fast installation, simple relocation, as well as easy retro-fitting of sprinklers. HD-FLEX sprinkler drops are FM approved and UL Listed. These flexible drops are contractor-friendly and have required brackets and connections for attaching sprinkler head of choice. HD-FLEX sprinkler drops are available in four sizes with option of braided and unbraided stainless steel hoses. Complete unit consists of a corrugated stainless steel flexible hose with nipple, reducer, bar and brackets.

Description

• “HD-FLEX” Flexible Sprinkler Connections
• Complete unit consists of a Corrugated Stainless Steel Flexible with Nipple, Reducer, Square Bar and Brackets
• Sizes: 700/800MM, 1000MM, 1200MM, 1500MM
• Max Service Pressure : 14 Bar (200 psi)
• Material of Construction: Stainless Steel
• Support Brackets, Inlet/Outlet Connectors and Square Bar - Mild steel, zinc plated
• UL Listed and FM Approved

Advantages

• Reduced labour costs and faster installation time
• Easy relocation of sprinklers within a short distance with ceiling modifications without re-cutting or modifications of existing pipe and fittings
• Ability to be installed in various types of ceilings
• Ideal for installation in seismic or vibrating applications
• Ideal for fast track construction projects
• Fewer tools required for installation

Download

• Product Catalogue
• UL Approval Certificate
• FM Approval Certificate
