Safety and Relief Valve

AL-150L - Safety and Relief Valve

Price: Contact

  • Model: AL-150L

    •

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Safety and Relief Valve

    AL-150L

    DOWNLOAD CATALOG

    * Blow-off test can be executed manually
    * Small and compact lever type
    * Superior durability of stainless steel trim

    Specifications

    Features Bronze, screwed, with lever
    Type Safety relief valve
    Specifications Product type Safety valve/Relief valve
    Nominal size 15A (1/2") - 50A (2")
    Application Steam, air
    End connection JIS Rc
    Working pressure 0.05 - 1 MPa
    Max. temperature 220 degree(C)
    Material Body Bronze
    Spring case Bronze
    Valve and valve seat Stainless steel (SCS14A)

    Remarks



    Dimensions and Weights
    Size L (mm) H1 (mm) Weight (kg)
    15A(1/2) 34 40 0.8
    20A(3/4) 38 43 0.9
    25A(1) 43 51.5 1.2
    32A(1 1/4) 50 61.5 1.9
    40A(1 1/2) 60 60 2.9
    50A(2) 75 76 4.8
